Universal GPS Navigation Magnetic Antenna – Blue FAKRA
$39.95
In stock (can be backordered)
- Product Description
- Product Installation
- Product Features
- Vehicle Compatibility
- Reviews (28)
- Shipping & Delivery
Description
This antenna has the blue FAKRA connector and is designed to install anywhere behind your RER navigation radio just beneath your dash top (under your windshield) in clear sight of the sky. It can be mounted & secured with its magnetic base (against any metal object under dash top) or with double-sided tape. Once installed, drive the vehicle to calibrate the system and to link to GPS satellites. If your navigation radio has been programmed correctly, your location should populate automatically.
Product Installation
Make sure you’re receiving at least 3 satellites after installation. Press NAV, MENU, NAV SETTINGS, GPS INFORMATION.

Product Features
Electrical:
Center Frequency:  1575.42MHz ±3 MHz
VSWR (Voltage Standing Wave Ratio):Â Â Â 1.5:1
Band Width:  ±5 MHz
Impedance:Â Â 50 ohm
Peak Gain:   >3dBic Based on 7×7cm ground plane
Gain Coverage:   >-4dBic at –90°<0<+90°(over 75% Volume)
Polarization:Â Â Â RHCP Antenna
Amplifier:
LNA Gain (Without cable):Â Â 28dB Typical
Noise Figure:Â Â Â 1.5dB
Filter Out Band Attenuation:
f0=1575.42 MHZ
7dB ï¼in f0+/-20MHZ
20dB ï¼in f0+/-50MHZ
30dB ï¼in f0+/-100MHZ
VSWR (Voltage Standing Wave Ratio):  <2.0
DC Voltage:Â Â 3V to 5V
DC Current:Â Â Â 5mA, 10mA Max
Mechanical:
Weight:   <110 grams
Size:   48×39×14.1mm
Cable:Â RG174 2 meters in length
Connector:Â Â Â Blue FAKRA
Mounting:Â Â Magnetic base
Housing:Â Â Black Shell
Environmental:
Working Temperature:   -40℃~ +85℃
Vibration:Â Â Sine Sweep 1g(0-p) 10~50~10Hz each axis
Humidity:Â Â Â 95%~100% RH
Weatherproof:Â Â Â 100%
Vehicle Compatibility
| Car Make & Model | Car Year |
|---|---|
| Chrysler Sebring | 2007 2008 2009 2010 |
| Dodge Avenger | 2007 2008 2009 2010 |
| Dodge Nitro | 2007 2008 2009 2010 |
| Jeep Wrangler | 2007 2008 2009 2010 |
| Chrysler 300 | 2008 2009 2010 |
| Chrysler Aspen | 2008 2009 |
| Chrysler Town & Country | 2008 2009 2010 |
| Dodge Challenger | 2008 2009 2010 |
| Dodge Charger | 2008 2009 2010 |
| Dodge Dakota | 2008 2009 2010 |
| Dodge Durango | 2008 2009 |
| Dodge Grand Caravan | 2008 2009 2010 |
| Dodge Journey | 2008 2009 2010 |
| Dodge Magnum | 2008 |
| Jeep Commander | 2008 2009 2010 |
| Jeep Grand Cherokee | 2008 2009 2010 |
| Jeep Liberty | 2008 2009 2010 |
| Dodge Caliber | 2009 2010 |
| Dodge Ram 1500 | 2009 2010 |
| Jeep Compass | 2009 2010 |
| Jeep Patriot | 2009 2010 |
| Dodge Ram 2500 | 2010 |
| Dodge Ram 3500 | 2010 |
